Description
Description
The UKU Local controller by HUUM is a complete control system for electric sauna heaters up to 18 kW, supplied here with the black glass control panel. It works with heaters from different manufacturers, sets the sauna between 40 °C and 110 °C, and brings overheating protection, failure detection, door monitoring and a child safety lock as standard. The set includes the control panel, main module, safety and bench sensors and a door sensor kit, and the system also switches a steamer and sauna lighting or ventilation. This is version 4.2, supplied with orders placed on or after 6 March 2026; models purchased before that date are version 4.1 or earlier. Wi-Fi capability can be added later through the HUUM mobile app, and other panel finishes, including white and wooden surrounds, are sold as separate listings.
Features
Technical Specification
| Maximum heater power | 18 kW (maximum 6 kW per heating circuit) |
| Target temperature | 40–110 °C (up to 90 °C with the bench sensor) |
| Heating time options | 3 or 6 h (private saunas); 12 h (semi-public); 18 h (public) |
| Electrical supply | 230 V 1N~ (heaters up to 12 kW) or 400 V 3N~ (heaters up to 18 kW) |
| Control panel (L × W × D) | Black glass; 105 × 55 × 22 mm |
| Control panel cable | 3 m supplied; maximum length 15 m |
| Main module (L × W × D) | 142 × 90 × 58 mm |
| Sensors | Safety sensor and bench sensor with two housings; maximum sensor cable length 15 m |
| Door sensor | Door sensor kit included |
| Steamer output | 300–2,500 W, 230 V |
| Lamp/ventilation output | Up to 100 W, 230 V |
| Wi-Fi (after app upgrade) | 2.4 GHz networks, 802.11 b/g/n |
| Version | UKU 4.2 (orders on or after 6 March 2026; earlier purchases are version 4.1 or earlier) |
| Designed to standard | EN 60335-2-53 |
| SKU | H2005021 |
| Cable sizes: supply to main module, 230 V single phase (SWA) | |
| 3.5 kW | 3 × 2.5 mm² |
| 4.5 kW | 3 × 4 mm² |
| 6 kW | 3 × 6 mm² |
| 9 kW | 3 × 10 mm² |
| 10.5 kW | 3 × 10 mm² |
| Cable sizes: supply to main module, 400 V three phase (SWA) | |
| 4.5 kW | 5 × 1.5 mm² |
| 6 kW | 5 × 1.5 mm² |
| 9 kW | 5 × 2.5 mm² |
| 10.5 kW | 5 × 2.5 mm² |
| 12 kW | 5 × 4 mm² |
| 15 kW | 5 × 4 mm² |
| 18 kW | 5 × 6 mm² |
| Cable sizes: main module to heater, 230 V single phase (SiHF) | |
| 3.5 kW | 3 × 2.5 mm² |
| 4.5 kW | 7 × 1.5 mm² |
| 6 kW | 7 × 2.5 mm² |
| 9 kW | 7 × 2.5 mm² |
| 10.5 kW | 7 × 2.5 mm² |
| Cable sizes: main module to heater, 400 V three phase (SiHF) | |
| 4.5 kW | 5 × 1.5 mm² |
| 6 kW | 5 × 1.5 mm² |
| 9 kW | 5 × 2.5 mm² |
| 10.5 kW | 5 × 2.5 mm² |
| 12 kW | 5 × 4 mm² |
| 15 kW | 5 × 4 mm² |
| 18 kW | 5 × 6 mm² |
Installation
Installation must be carried out by a licensed electrician, with the power turned off at the circuit while work takes place. The main module is best installed outside the sauna room on a dedicated circuit, and the manufacturer recommends connecting the control system to the mains without a residual current circuit breaker. The black glass control panel recesses into the wall (a 65 × 105 × 27 mm recess is required) or mounts on the surface with the UKU mounting frame, sold separately; inside the sauna it must sit with its upper edge no higher than 1 m from the floor and at least 50 cm from any exhaust ventilation. The controller is not IP-certified and cannot be placed outdoors unless installed in an IP-rated enclosure. The installation manual in the Downloads tab and local wiring regulations must be followed.
Brand
HUUM is an Estonian sauna brand that pairs age-old sauna knowledge with modern Nordic design. Its DROP heater won the Red Dot Award for Product Design in 2015.
Warranty
The warranty card is available in the Downloads tab.
Ordering note
Check your heater model, heater power and controller generation (UKU 4.1 or 4.2) before ordering. Electrical installation must be carried out by a certified electrician.
